6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ – TPLINK TL-SF1006P


  • Item Code: 101643
  • Brand: TPLINK
  • Model: TL-R480T+
  • Item Condition: New
  • Color: Black
  • Packaging: Carton Box

KSh 5,700.00

Compare
Spread the love

6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ – TPLINK TL-SF1006P:

Key Features

  • 6ร— 10/100 Mbps RJ45 ports
  • 4ร— PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Up to 250m data and power transmitting range under Extend Mode
  • Priority Mode ensures high priority of ports 1โ€“2ย to guarantee the quality of sensitive application
  • PoE Auto Recovery guarantees stable operation of PoE devices by automaticallyย rebooting the dropped or unresponsive PD devices
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 67 W for all PoE ports
  • Plug and play with no configuration required

Specifications

Brand: TPLINK
Model: TL-SF1006P
Condition: New
Color: Black
Packaging: Carton box
Included in Package: โ€ข TL-SF1006P
โ€ข Power Adapter
โ€ข Installation Guide
Country of Origin: China

HARDWARE FEATURES

Interface โ€ข 6ร— 10/100 Mbps RJ45 Ports (ports 1โ€“4 support 802.3af/at PoE+)
โ€ข AUTO Negotiation
โ€ข AUTO MDI/MDIX
Network Media โ€ข 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
โ€ข EIA/TIA-568 100ฮฉ STP (maximum 100m)
โ€ข 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
โ€ข EIA/TIA-568 100ฮฉ STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output: 53.5 V DC / 1.31 A)
Packet Forwarding Rate 0.8928 Mpps
PoE Ports (RJ45) โ€ข Standard: 802.3 af/at compliant
โ€ข PoE Ports: Ports 1โ€“4
โ€ข Power Supply: 67 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1.2 Gbps
Dimensions ( W x D x H ) 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm)
Max. Power Consumption โ€ข 2.52 W (220 V / 50 Hz, no PD connected)
โ€ข 75.4 W (220 V / 50 Hz, with 67 W PD connected)
Max Heat Dissipation โ€ข 8.59 BTU/h(no PD connected)
โ€ข 257.11 BTU/h(with 67 W PD connected)

SOFTWARE FEATURES

Advanced Features โ€ข Compatible With IEEE 802.3af/at Compliant PDs
โ€ข Extend Mode Button (Ports 1โ€“4)
โ€ข Priority Mode Button (Ports 1โ€“2)
โ€ข PoE Auto Recovery (Ports 1-4)
โ€ข Mac Address Auto-Learning and Auto-Aging
โ€ข IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode
Transmission Method Store-And-Forward

OTHERS

Certification FCC, CE, RoHS

More info here …
