2.4GHz 300Mbps 9dBi Outdoor CPE – TPLINK CPE210

Brand: TP-LINK

Item Code: 101596
Brand: TPLINK
Model: CPE210
Item Condition: New
Color: White
Interfaces:
- 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)
  1 Grounding Terminal

  1 Reset Button
Power Supply:
- Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
  Voltage range: 16-27VDC
Max. Power Consumption: 5 Watts Max
Enclosure:
- Outdoor ASA stabilized plastic material
  IPX5 waterproof Certification
Wireless Standards: IEEE 802.11b/g/n (with Pharos MAXtream disabled)
Proprietary Protocol: TDMA Mode (with Pharos MAXtream enabled)
Frequency: 2.4~2.483GHz
Packaging: Carton Box

... people are viewing this right now

KSh 7,500.00

Description

2.4GHz 300Mbps 9dBi Outdoor CPE – TPLINK CPE210: TP-Link’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.

Key Features

- Built-in 9dBi 2×2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 25dBm/500mw
- System-level optimizations for more than 5km long-range wireless transmission
- TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
- Centralized Management System – Pharos Control
- AP / Client / AP Router / AP Client Router (WISP) operation modes
- Passive PoE Adapter supports up to 60 meters (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

Specifications

Brand:	TPLINK
Model:	CPE210
Condition:	New
Color:	White
Interfaces:	1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1 Grounding Terminal 1 Reset Button
Power Supply:	Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Max. Power Consumption:	5 Watts Max Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
Antenna:	Built-in 9dBi 2×2 Dual-polarized Directional Antenna Beam Width: 65° (H-Plane) / 40° (E-Plane) Note: For more details, please refer to datasheet
Protection:	15KV ESD Protection 6KV Lightning Protection
Enclosure:	Outdoor ASA stabilized plastic material IPX5 waterproof Certification
Wireless Standards:	IEEE 802.11b/g/n (with Pharos MAXtream disabled)
Proprietary Protocol:	TDMA Mode (with Pharos MAXtream enabled)
Wireless Speeds:	Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic)
Frequency:	2.4~2.483GHz Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used.
Transmission Power:	25dBm/316mw (Adjustable power by 1dBm) Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used.
Processor:	Qualcomm Atheros 560MHz CPU, MIPS 74Kc
Memory:	64MB DDR2 RAM, 8MB Flash
Certifications:	CE, FCC, RoHS, IPX5
Wireless Configurations:	Pharos MAXtream TDMA Technology 802.11b/g/n Modes Selectable Channel Width: 5/10/20/40MHz Automatic Channel Selection Transmission Power Control Dynamic Frequency Selection (DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging (AP mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: > Beacon Interval/RTS Threshold/Fragmentation >Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Management Features:	Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System Log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server
System Tools:	Wireless Signal Quality Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute
System-level Optimizations:	Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog
POE ADAPTER FEATURES
Dimensions(W x D x H):	85.8×43.9×29.7 mm
Interfaces:	1 AC Jack with Earth Ground 1 10/100Mbps Shielded Ethernet Port (Power + Data) 1 10/100Mbps Shielded Ethernet Port (Data)
Button:	Remote Reset Button
Power Status LEDs:	Green
Input:	100-240VAC, 50/60Hz
Output:	• V2.0: 24VDC, 0.6A Max • V3.0: 24VDC, 0.5A Max • V3.20: 24VDC, 0.25A Max+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Efficiency:	>80%
Certifications:	CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
Dimensions (W×D×H):	11×3.1×2.1 inch (276×79×60 mm)
OTHER SPECIFICATIONS
Packaging:	Carton box
Included in Package:	Outdoor Wireless CPE 24V 0.6A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide
Country of Origin:	China
