16-Port Gigabit Easy Smart Switch – TPLINK TL-SG1016DE: This switch provides you with an ideal upgrade from an unmanaged switch, designed for Small and Medium Business networks that require simple network management. Network administrators can effectively monitor traffic via Port Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your business network, TL-SG1016DE offers Port Priority/802.1P Priority and DSCP QoS1 to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG1016DE can save power consumption, making it an eco-friendly solution for your business network.
Key Features:
- 16 10/100/1000Mbps RJ45 ports
- Provides network monitoring, traffic prioritization, loop preventoin and VLAN features
- Green technology reduces power consumption
- Simple network set-up on top of plug-and-play connectivity
- Web-based user interface and management utility simplify configuration
Specifications
Brand: | TPLINK |
Model: | TL-SG1016DE |
Condition: | New |
Color: | Black |
Interface: | 16 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
Standards and Protocols: | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x |
Network Media: | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
Fan Quantity: | Fanless |
Physical Security Lock: | No |
Power Supply: | 100-240VAC, 50/60Hz |
Max. Power Consumption: | 10.54W (220V/50Hz) |
Max Heat Dissipation: | 35.94 BTU/h |
Switching Capacity: | 32Gbps |
Packet Forwarding Rate: | 23.8Mpps |
MAC Address Table: | 8K |
Packet Buffer Memory: | 4.1Mbit |
Jumbo Frame: | 10KB |
Transmission Method: | Store-and-Forward |
Mounting: | Rack Mountable |
Dimensions (WxDxH): | 11.6 × 5.5 × 1.7 in. (294 × 140 × 44 mm) |
Quality of Service: | Support Port-based/802.1p/DSCP priority Support 4 priority queues Rate Limit Storm Control |
L2 Features: | IGMP Snooping V1/V2/V3 Static Link Aggregation Port Mirroring Cable Diagnostics Loop Prevention |
VLAN: | Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) MTU/Port/Tag VLAN |
Certification: | FCC, CE, RoHs |
Environment: | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing |
Packaging: | Carton box |
Included in Package: | TL-SG1016DE Power Cord Installation Guide Rackmount Kit Rubber Feet |
Country of Origin: | China |
